8 Instructions for Use iMotion 1301/1301.S /1401 T-1305 e
– Continuedoperationforacertainperiodinthecurrentoperatingmodebymeansofabatteryunitu.
– Unlockingandopeningof thedoorfromoutsidebymeansofakeyswitchandthebatteryunitu.
3.3 Operating Modes
The automatic door system can be operated with the TORMAX user interface u (6 operating modes and
statusdisplay)orwithanoperatingmodeswitchu (3operatingmodes).
Operating Mode OFF
Theinternalandexternalsensorsaredisregarded.Thedoorismechanicallyheldintheclosedposition
and locked using an electric lock u. Access is only possible using the key switch or if the door is manu-
ally unlocked using a key or the door handle is used to open the door manually.
< The door can still be used for 5 seconds after selecting operating mode OFF. The door then locks at
the end of this period as soon as it is closed. The transition is signalled on the user interface by the flash-
ing display of operating mode OFF.
Operating Mode AUTOMATIC 1
The operating mode AUTOMATIC 1 is normally used during the day. The door opens automatically through
the inside and outside sensors. The door can behave differently depending on the settings programmed
during commissioning:
“Push-and-Go”
If the door is manually pushed in the opening direction, it reacts as if to a command to open: it opens
automatically, waits for the hold-open time and then closes.
Systems with an Electric Door Lock u
The lock unlocks on every valid opening impulse. The door lock must be manually unlocked with the door
handle before it is possible to open the door with the “Push- and-Go” system. In this operating mode the
door lock can also be permanently unlocked depending on the setting programmed at the time of com-
missioning.
Operating Mode AUTOMATIC 2
Corresponds to operating mode AUTOMATIC 1 but a different motional sequence can be set during com-
missioning(e.g.asloweropeningmovement,differentopenpositionsandalongerhold-opentime).
Operating Mode EXIT
Operating mode EXIT is normally used for the period before the shop or office closes. The door will only
openautomaticallywhenactivatedbytheinternalsensor.Whenthedooropenstheexternalsensoris
also monitored for safety reasons. The open position is determined by the preceding selection of the op-
erating mode AUTOMATIC 1 or AUTOMATIC 2. Additionally the door can be locked automatically by the
door lock u. The door lock can be permanently unlocked in this operating mode in case of need.
Operating Mode OPEN
The door opens and remains open. The open position is determined by the preceding selection of the
operatingmodeAUTOMATIC1orAUTOMATIC2.Thedooropensagainonreceivingthenextopenimpulse
or when changing the operating mode to OFF and back again to OPEN.
Operating Mode Manual Operation
The door leaf can be freely moved. This operating mode can be used for cleaning the door leaf or for
temporarily shutting down the door. The system is reset after leaving this operating mode.
In this operating mode the door lock can also be permanently unlocked depending on the setting pro-
grammed at the time of commissioning.
