16
BATTERY CHARGING USING THE ON-BOARD CHARGER (OPTIONAL)
Take the machine to a level surface near a power plug.
1. Turn off the machine using the key switch.
2. Insert the main plug into the main socket.
3. Proceed with the charge keeping the recovery tank lifted (see paragraph “ACCESS TO THE
BATTERY COMPARTMENT” in “BEFORE USE”).
4. Do not take off the plug from the main socket until the indication of the end of charge is
displayed.
At the end of the charge, take off the plug from the main socket.
Never charge the batteries with a non suitable battery charger.
Carefully follow the instructions provided by the battery charger and the batteries
manufacturers.
NOTE: Never leave the batteries completely discharged for long periods of time even if the
machine is not used. In case of traditional batteries, please check the electrolyte level every
20 charging cycles and eventually fill them up with distilled water. Never leave the batteries
discharged for more than two weeks.
If lead/acid batteries are installed there could be the risk of gas exhalations and emission of
corrosive liquids.
Fire danger: do not approach with free flames.
ASSEMBLY
ASSEMBLING THE BRUSH
To assemble the brush it is necessary to have the brush base lifted from the floor. If it is not in
such position, proceed as follows:
Without having an operator aboard, turn the key to switch on the display, then after 3 seconds,
automatically all the working assemblies will reset themselves and lift from the floor.
Turn off the machine using the key switch.
With the brush base lifted, manually rotate the brush until the central screw, where to fix the
support and to lock the brush, can be seen. Secure the brush as shown in the picture.
Use only brushes provided with the machine or the ones specified on the “BRUSHES and
OPTIONAL” manual. Using other brushes could compromise the good cleaning.
