10
OPERATION INSTRUCTIONS
Main Controls:
Your extractor is equipped with (4) main switches, which control the spray bar, the brush
motor, the vacuum motor and the main power. The main switch must be activated before
operating the transaxle drive. The machine will glide easily across the floor when pushed
forward (without power).
WARNING:
In order to avoid injury, it is recommended that the extractor be pulled in the reverse
direction (without power) in emergency situations only.
In addition, there are (4) main circuit breakers, (located on the front of the main control
panel):
- (20 amp) circuit breaker – main power
- (15 amp) circuit breaker – vacuum motor
- (2.5 amp) circuit breaker – transaxle drive
- (2.5 amp) circuit breaker – brush motor drive
