2
This illustrated parts book covers:
CATALOG NO. 98190
SERIES “D”
SIZE 22”
CAPACITY 20 Gal.
VOLTS 115V
AMPS 15
All specifications are subject to change without notice.
TABLE OF CONTENTS:
Safety Instructions 3, 4 & 5
Preparation & General Precautions 5, 6 & 7
Cleaning Tips 8
Machine Specifications 9
Operation Instructions 10,11,12
Maintenance Issues 12,13
Trouble Shooting Table 14
Main Assembly 15
Upper Tank Assembly 16,17
Lower Tank Assembly 18,19, 20
Control Panel Assembly 21,22
Brush Assembly 23,24
Pump Assembly 25
Recovery Dome Assembly 26
Wiring Diagram 27, 28
Tornado
®
Standard Warranty Program*
10 Years: All plastic tanks and rotationally-molded bodies
2 Years: Parts and Labor on all Tornado and Tornado/Karcher cleaning equipment **
1 Year: Warranty on batteries, one full year, not pro-rated.
Warranties do not cover components subject to normal wear or abuse and misuse, and have other
limitations not specified here. For full details, contact your Authorized Tornado Distributor, Service
Center, or the Tornado Technical Service Department.
* Effective January 1
st
, 2000. Terms subject to change without notice.
** Windshear™ Blower-Dryer, Insulation Blowers, CW 50, CW 100, and Duo Upright Carpetkeepers™ are warranted
for 1 (one) year for parts and labor.
