12
12. As you are cleaning, monitor the water level in the
recovery tank cover. An overflow of water in the recovery
tank can damage the vacuum motor. Always be aware of
this water level.
13.The recovery tank can be drained by removing the drain
hose from its support clip and removing the drain plug. The
standpipe in the recovery tank is equipped with a metal
screen cap. This cap is accessible by removing the clear
dome on top of the unit. It is recommended that this cap be
cleaned after every machine use.
14.The solution tank has a clear see through drain hose,
which tells the operator the tank level. The water in the
solution tank can be drained using this hose.
15.While cleaning, pre-spray traffic areas and spots using the
spray wand. The spray wand is attached to a quick
disconnect and is pressurized when the MAIN SWITCH is
turned on.
WARNING:
To avoid serious injury: Disconnect power before servicing. Electrical service must be
performed by an authorized service station or electrician. Use only nonflammable
commercial chemicals intended for machine application. Do not use where explosive
vapors or dust are present in the air. Disconnect power if the machine is left
unattended. Do not allow machine to freeze. Do not expose to rain, store machine
indoors.
Daily Maintenance:
1. Rinse out the recovery tank and clean the recovery dome. In addition, remove and
clean the recovery screen cap.
2. Drain the solution tank and clean with water.
3. Remove any debris in either the recovery or solution tank.
4. Flush the pumping system with clean warm water or white vinegar.
5. Remove lint or debris from the vacuum shoe or brush. Hint: if heavy lint build-up is
present, use a hacksaw blade with teeth down to remove the lint.
