INSTALLATION − DECO 20a / DEC0 26a / DECO 20e / DECO 26e
300561 en − 05/08 Chap. 3.6 /16
3.6 ELECTRIC INSTALLATION
Δ Danger !
For connecting and any other work on the electric equipment, the power must be cut off. The work must be carried out only by an authorized technician to
avoid the danger of electrocution.
Deficient connections may also cause serious damage to the installation.
Fig.106
QS0
XS94
XS1
Lathe’s input terminal box
Autotransformer
Fig.107
TC1
to mains
Autotransformer
XS38
To Next Page
