tornos DECO 20a - Safety Measures & Devices; Standard Machine Data

INSTALLATION − DECO 20a / DEC0 26a / DECO 20e / DECO 26e
300561 en − 05/08 Chap. 1.2 /1
1. GENERAL
1.1 SAFETY MEASURES & DEVICES
These are described in the Instructions 300480: SAFETY REGULATIONS
DECO 2000.
ΔWarning !
Failure to comply with the safety regulations may
cause serious accidents.
1.2 STANDARD MACHINE DATA
Feature Notes
DECO 20a
data
DECO 26a
data
Length : 2270 mm 2270 mm
Width : 1550 mm 1550 mm
Height : without signal lamp 2220 mm 2220 mm
Enclosure weight : approx. 650 kg 650 kg
Full weight : approx. 3300 kg 3750 kg
Specific load : per surface unit 12.0 daN/cm
2
13.9 daN/cm
2
⇒ Note :
For more details, consult your operating instructions entitled :
OPERATION & MAINTENANCE.
⇒ Note :
For more details, consult your operating instructions entitled :
MACHINE EQUIPMENT.
DETAILED DIMENSIONS
− See Para. LOCATION AND INSTALLATION
