AdjustingtheHeightofCut
(HOC)
Model03192Only
OnModel03192,adjusttheheightofcut(HOC)
byaddingorremovingtheadjustment(slotted)rear
spacersbelowthesideplatepadonthecuttingunit.
Note:Spacersinstalledabovethesideplatepaddo
notaffectHOC.
Theadjustment(slotted)rearspacersarestored
abovethesideplatepad;toincreaseHOC,move
thembelowthesideplatepad.
Thereare2typesofslottedrearspacersusedfor
adjustingHOConModel03192cuttingunits:
•1/4inch(6.4mm)slottedrearspacers,upto3on
eachside.
•0.075inch(1.9mm)thinslottedrearspacers,up
to2oneachside.
Additionallythereare5xedrearspacers(1/4inch,
6.4mm)alwayslocatedbelowthesideplatepad.
Important:Donotremoveoradjustthe5lower
rearspacers;thiscuttingunitisdesignedto
operateataHOCbetween1.25to2.00inches(32
to51mm)andremovingthelowerxedspacers
causestheHOCtoleavethatrange.
g341920
Figure18
1.Thin(0.075inch)
adjustmentspacers
3.Sideplatepad
2.1/4inchadjustment
spacers
4.Lowerxedspacers(do
notadjust)
Height-of-CutChart(Model03192)
HOCSettingNo.of1/4inch
RearSpacers*
No.ofThin
RearSpacers*
32mm(1.25inches)
5
0
34mm(1.33inches)
5
1
35mm(1.38inches)
5
2
38mm(1.50inches)
60
40mm(1.58inches)
61
42mm(1.65inches)
62
45mm(1.75inches)
7
0
46mm(1.83inches)
7
1
48mm(1.90inches)
7
2
51mm(2.00inches)
80
*Installedbeneaththesideplatepad.
ToadjusttheaggressivenessofcutonModel
03192cuttingunits,proceedasfollows:
•Installthecuttingunitontothetractionunitas
describedinthetractionunitOperator'sManual.
•Loosen,butdonotremove,thelocknutsatthe
frontofthexedplatesandremovethecarriage
bolts,spacers,andlocknutsfromtherearofthe
xedplatesandadjusttheirposition.
Note:Toachievealessaggressivecut,mount
thecuttingunitlinksinthenumber1positionor
mountthelinkstothenumber3positionfora
moreaggressivecut(Figure19).
g341875
Figure19
Leftsideshown
1.Lessaggressive3.Moreaggressive
2.Production/Standard
4.Justloosenthese
locknutsbeforeadjusting
aggressivenessofcut
