g028640
Figure4
1.Capscrew(2)3.Greasetting
2.Setscrew4.Greasevent
2.Installthestraightgreasetting(Figure4).
2
AdjustingtheCuttingUnit
NoPartsRequired
Procedure
1.Adjustthebedknifetothereel.
2.Adjusttherearrollerforyourheight-of-cut
requirements.
3.Settheheightofcut.
4.Adjusttherearshieldifnecessary.
RefertoAdjustingtheCuttingUnit(page8)
forcompleteinstructionsforperformingthese
adjustments.
3
InstallingtheReelMotors
Partsneededforthisprocedure:
1
O-ring
2
Capscrews(maycomeassembled)
Procedure
Important:Beforeinstallingthereelmotors,
obtainandinstallthecounterweightsorother
accessoriesontheoppositesideofthecutting
unitsfromthereelmotorsasdescribedin
theinstructionsprovidedwiththeweightsor
accessories.
1.Installthecuttingunitsontothetractionunit;
refertothetractionunitOperator’sManualsfor
instructions.
2.Iftherearenocapscrewsonthereel-motorside
plate,installthem(Figure4).
3.InstalltheO-ringonthereelmotor(Figure5).
g191072
Figure5
1.O-ring
4.Installthereelmotorandsecureitwiththecap
screws.
5.Greasethesideplateuntilexcessgreasecomes
outofthegreasevent(Figure4).
