Toro 03188 - Adjusting the Shop Roller Assemblies

AdjustingtheShopRoller
Assemblies
Model03192Only
Beforeyoulowerthecuttingunitstotheshopooror
removethemfromthetractionunit,lowertheshop
rollerassembliestoprotectthereelandbedknife
bladesfromhardsurfacecontact.
Beforeoperatingthecuttingunits,installthemtothe
machine,raisethecuttingunits,andraisetheshop
rollerassembliestopreventthemfromtouchingthe
grassandinterferingwithoperation.
1.Removethecotterpinfromtheclevispinthat
securestheshoprollerbrackettothesideplate.
2.Positiontheshoprollerassemblyasneeded:
•Lowertheshoprollerbracketsbeforethe
cuttingunitisloweredtotheshopooror
removedfromthetractionunit(Figure13).
g341821
Figure13
1.Clevispin(alwaysinstalled
inthetopsquareholein
thesideplate)
3.Shoprollerassembly(in
lowered/shopposition)
2.Sideplate
•Raisetheshoprollerbracketsafterthe
cuttingunitisraisedtotheoperatingposition
(Figure14).
g341820
Figure14
1.Clevispin(alwaysinstalled
inthetopsquareholein
thesideplate)
3.Shoprollerassembly(in
raised/operatingposition)
2.Sideplate
Note:Ensurethattheclevispinisalways
installedinthetopsquareholeintheside
plate.
3.Securetheshoprollerbrackettotheclevispin
withthecotterpin.
4.Repeatthisprocedureontheoppositeendof
thecuttingunit,andforallothercuttingunitsas
needed.
11
