Maintenance
UsingtheKickstandwhen
TippingtheCuttingUnit
Wheneverthecuttingunithastobetippedtoexpose
thebedknife/reel,propuptherearofthecuttingunit
withthekickstand(suppliedwiththetractionunit)to
makesurethatthenutsonthebackendofthebedbar
adjustingscrewsarenotrestingontheworksurface
(Figure23).
g191340
Figure23
1.Kickstand
LubricatingtheCutting
Units
Regularlylubricatethe5greasettingsofeachcutting
unit(Figure24)withNo.2lithiumgrease.
Thereare2lubricationpointsonthefrontroller,2on
therearroller,and1atthereel-motorspline.
Note:Model03192doesnothaveafrontroller;there
areonlythe2lubricationpointsontherearrollerand
1atthereel-motorspline.
Important:Lubricatingthecuttingunits
immediatelyafterwashinghelpspurgewaterout
ofthebearingsandincreasesbearinglife.
1.Wipeeachgreasettingwithacleanrag.
2.Applygreaseuntilcleangreasecomesoutof
therollersealsandthebearingreliefvalve.
3.Wipeanyexcessgreaseaway.
g191601
Figure24
Greasettingsonthereel-motorside
1.Bearingreliefvalve
