Toro 03188 - Setup; Installing the Reel Grease Fitting

Setup
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
ProcedureDescription
Qty.
Use
1
Straightgreasetting
1
Installthereelgreasetting.
2
Nopartsrequired
–
Adjustthecuttingunit
O-ring
1
3
Capscrews(maycomeassembled)
2
Installthereelmotors.
4
Nopartsrequired
–
Adjusttheshoprollerassembly
positions(Model03192only).
MediaandAdditionalParts
Description
Qty.
Use
Operator'sManual
1
PartsCatalog(notincluded)—refertothe
includedpostcardforinformationonobtaining
thePartsCatalog.
–
Reviewthematerialandsaveitinanappropriateplace.
Note:Determinetheleftandrightsidesofthe
machinefromthenormaloperatingposition.
1
InstallingtheReelGrease
Fitting
Partsneededforthisprocedure:
1
Straightgreasetting
Procedure
Installthegreasettingonthereel-motorsideof
thecuttingunit.RefertoFigure3todeterminethe
positionofthereelmotorsbasedonthepositionofthe
cuttingunitonthemachine.
g034633
Figure3
1.Cuttingunit1
4.Weight
2.Cuttingunit2
5.Reelmotor
3.Cuttingunit3
1.Removeanddiscardthesetscrewonthe
reel-motorsideplate(Figure4).
