Toro 03781 - Lower Mow;Raise Control Lever; Throttle-Control Lever; Mow-Speed Limiter

Lower Mow/Raise Control Lever
G453725
Lower the cutting units
Raise the cutting units
Note: The lever also starts and stops
the reels when the reels are enabled in
the mow mode.
The cutting units cannot be lowered
when the mow/transport lever is in the
transport position.
Throttle-Control Lever
G447509
Move the throttle-control lever
forward to increase the engine
speed and rearward to decrease
speed.
Mow-Speed Limiter
G467875
Rotate limiter forward—allows the cutting units to
engage and limits the maximum ground speed
during mowing.
Rotate limiter backward—to achieve maximum
ground speed between job sites.
Spacers—change the position to adjust mowing
ground speed.
Forward speed-limiter screw—adjust to limit the
amount the traction pedal can be pressed in the
forward direction.
Reverse speed-limiter screw—adjust to limit the
amount the traction pedal can be pressed in the
reverse direction.
IMPORTANT
The speed-limiter screws must stop the traction
pedal before the pump reaches full stroke;
otherwise, damage to the pump may occur.
3466-706A Page 4–4 Product Overview: Controls
