Toro 04613 User Manual

G020095
Figure8
1.Height-of-cutarm
3.Adjustingbolt
2.Locknut
2.Loosenthenutonthegaugebarandsettheheight
adjustingbolttothedesiredheight-of-cut(Figure9).
Thedistancebetweenthebottomoftheboltheadand
thefaceofthebaristheheight-of-cut.
Figure9
1.Gaugebar
3.Nut
2.Heightadjustingbolt
3.Hooktheboltheadontothecuttingedgeofthe
bedknifeandresttherearendofthebarontotherear
oftheroller(Figure10).
Figure10
1.Gaugebar
4.Rotatetheadjustingboltontheheight-of-cutarms
untilthefrontrollercontactsthegaugebar.Adjust
bothendsoftherolleruntiltheentirerollerisparallel
tothebedknife.
Important:Whensetproperly,therearandfront
rollerswillcontactthegaugebarandthebolthead
willbesnugagainstthebedknife.Thisensures
thattheheight-of-cutisidenticalatbothendsof
thebedknife.
5.Tightenthenutstosecuretheadjustment.Donot
overtightenthenuts.Tightenthemenoughtoremove
playfromthewasher.
Note:Usethefollowingcharttodeterminewhich
bedknifeisbestsuitedforthedesiredheightofcut.
RecommendedBedknife/HeightofCutChart
Bedknife
PartNumber
HeightofCut
Edgemax
Micro-cut
(Standard)
115-18801.5–4.7mm
(0.062–0.188inch)
Edgemax
Tournament
(Optional)
115-18813.1–12.7mm
(0.125–0.500inch)
Micro-cut
(Optional)
93-42621.5–4.7mm
(0.062–0.188inch)
Tournament
(Optional)
93-42633.1–12.7mm
(0.125–0.500inch)
Extended
Micro-cut
(Optional)
108-43031.5–4.7mm
(0.062–0.188inch)
Extended
Tournament
(Optional)
108-43023.1–12.7mm
(0.125–0.500inch)
Low-cut
(Optional)
93-42644.7–25.4mm
(0.188–1.00inch)
High-cut
(Optional)
94-63927.9–25.4mm
(0.312–1.00inch)
Fairway
(Optional)
63-86009.5–25.4mm
(0.375–1.00inch)
6
