Toro 20016 User Manual

3354-613 Rev A
Deck, Side Chute and Rear Door Assembly
2
Ref Part No. Qty. Description
Screw-HH1
322-3
4
Plate-HOC, Front2
105-1808-03
2
Baffle-Front3
104-8694-03
1
Nut-Lock, NI4
3296-29
8
Housing5
104-7915
1
Decal-Danger5:1
105-6838
1
Decal-Deck6
105-1296
1
Nut-HHF7
32128-32
2
Screw-CARR8
3229-11
2
Spring-Torsion9
99-5293
1
Bracket-Cover10
99-5292
1
Rod-Cover11
99-5291
1
Chute-Discharge, Side12
105-3028
1
Discharge Door ASM13
106-8376
1
Latch-Door13:2
107-0795
1
Cap-Door13:3
107-7456
1
Screw-Plastite13:4
107-7461
1
Nut-Push15
32112-6
1
11 Inch RH HOC Plate ASM16
110-1635
1
Spring-Door, Rear18
105-3032
1
Rear Door ASM19
105-1323
1
Decal-Warning19:2
105-1295
1
Screw And Washer ASM22
46-6810
1
Screw-HWH23
46-8091
2
Ref Part No. Qty. Description
Plug-Discharge, Rear24
105-1842
1
Rod-Pivot, Rear Door25
105-1827
1
Plug-Dome27
104-9369
1
11 Inch LH HOC Plate ASM28
110-1634
1
Washer-Stepped29
105-3006
4
Baffle-Rear30
105-3047
1
3

Toro 20016 Specifications

General

Engine	Briggs & Stratton
Deck Material	Steel
Mulching Capability	Yes
Bagging Capability	Yes
Side Discharge	Yes
Engine Type	4-Cycle
Cutting Width	22 inches
Cutting Height	1 - 4 in (2.5 - 10 cm)
Power Source	Gas
Wheel Size	7 in (front)
