Toro 20016 - Setup Procedures; Unfolding the Handle Safely; Filling the Engine with Oil

3354-613 Rev A
Rear Axle Assembly
4
Ref Part No. Qty. Description
Shield-Trailing1
105-1843
1
Brace-Plate, HOC2
105-1811
1
Nut-Hex, Side Deform3
32153-3
2
Bushing-Mount4
110-1612
2
Knob-Lever, HOC5
105-3042
2
Arm-11 Inch Spring, Rear6
110-1630
2
Arm-Pivot, Rear7
105-1819
2
Washer-Wheel Bolt8
110-7466
2
11 Inch Wheel ASM9
110-1631
2
Bolt-Shoulder10
614650
2
Screw-HH11
322-6
4
Washer-Flat12
105-3048
2
Plug-Dome13
104-9373
3
Plug-Dome14
104-9368
1
Screw-HH15
322-3
2
Screw-CARR16
3229-11
4
Nut-Lock, NI17
3296-16
4
4
