Toro 20099 - Removing the Grass Bag

RemovingtheGrassBag
1.Routethestarterropearoundthelowerropeguide
(Figure23).
Figure23
1.Lowerropeguide
Note:Thelowerropeguidereleasesthestarterrope
whenyoupulltherecoilstarthandle.
2.Rotatethelockcounterclockwiseonthemulchplug
totheunlockedposition(Figure24).
Figure24
1.Lock
3.Raisethedischargedeectorandliftthegrassbag
upbythehandleoffthenotches.
4.Insertthemulchplugintotheopeningattherear
ofthemowerhousinguntilitsnapsintoplace
(Figure25).
Figure25
1.Dischargedeector
2.Reardischargeplug
5.Rotatetheleverlockclockwiseintothelocked
position(Figure26).
Figure26
1.Mulchplug3.Mulchpluglock
2.Tabs
6.Closethedischargedeector.
Note:Whenyouremovethemulchplug,unlock
theleverlock(rotateitcounterclockwise).
11
