Toro 20099 - Side-Discharging the Clippings; Installing the Side Discharge Chute; Removing the Side Discharge Chute

Side-dischargingtheClippings
Usethesidedischargeforcuttingverytallgrass.
Ifthebagisonthemower,removeitandinserttherear
dischargeplug(refertoRemovingtheGrassBag)before
side-dischargingtheclippings.
Important:Ensurethatthereardischargeplugis
lockedinplace(Figure27).
Figure27
1.Mulchplug3.Mulchpluglock
2.Tabs
Thebladeissharp;contactingthebladecan
resultinseriouspersonalinjury.
Stoptheengineandwaitforallmovingpartsto
stopbeforeleavingtheoperatingposition.
InstallingtheSideDischargeChute
1.Unlockthesidedischargedoor(Figure28).
Figure28
2.Liftopenthesidedischargedoor(Figure29).
Figure29
3.Installthesidedischargechuteandclosethedoor
ontothechute(Figure30).
Figure30
RemovingtheSideDischargeChute
Toremovethesidedischargechute,reversethesteps
above.
Important:Lockthesidedischargedoorafteryou
closeit(Figure31).
Figure31
12
