Toro 20099 - Assembling and Unfolding the Handle

112-8867
1.Lock2.Unlock
114-7982
1.Warning—readthe
Operator’sManual.
4.Cutting/dismemberment
hazardofhandorfoot,
mowerblade—stayaway
frommovingparts.
2.Thrownobject
hazard—keepbystanders
asafedistancefromthe
machine.
5.Cutting/dismemberment
hazardofhandorfoot,
mowerblade—donot
operateupanddown
slopes;operatesideto
sideonslopes;stopthe
enginebeforeleavingthe
operatingposition;and
lookbehindyouwhen
backingup.
3.Cutting/dismemberment
hazardofhandorfoot,
mowerblade—remove
theignitionkeyandread
theinstructionsbefore
servicingorperforming
maintenance.
115-8411
1.Unlocked2.Locked
Setup
Important:Removeanddiscardtheprotective
plasticsheetthatcoverstheengine.
1.AssemblingandUnfolding
theHandle
Procedure
Assemblingandunfoldingthehandle
improperlycandamagethecables,causingan
unsafeoperatingcondition.
•Donotdamagethecableswhenassembling
andunfoldingthehandle.
•Ensurethatthecablesareroutedtothe
outsideofthehandle.
•Ifacableisdamaged,contactanAuthorized
ServiceDealer.
1.Raisetherearofthemowerhousingtoitshighest
cuttingheightsettingbymovingthe2rearcutting
heightleversallthewayforward.RefertoAdjusting
theCuttingHeightintheOperationsection.
2.Attachthehandleendstothemowerhousingwith
2washersand2handlebolts(Figure3),butdonot
tightenthehandlebolts.
Figure3
1.Washer3.Handleend
2.Handlebolt
Important:Routethecables under thehandle
(Figure3).
3.Rotatethehandlerearward(Figure4).
4
