ProductOverview

g276361

Figure6

1.Sparkplug(underbrush

guard)

11.Drivebail

2.Side-dischargedeector12.Self-propeladjustment

3.Airlter13.Grassbag

4.Oilll/dipstick

14.Recoil-starthandle

5.Fuel-tankcap15.Rearcutting-heightlever

6.Reardeector16.Fuel-shutoffvalve

7.Blade-control-locklever

17.Oillter

8.Blade-controlbar18.Throttlelever

9.Parkingbrake19.Beltcover

10.Handle20.Frontcutting-heightlever

g019644

Figure7

1.Grassbag3.Side-dischargechute

2.Rear-dischargeplug

4.Side-dischargedeector

Controls

g019652

Figure8

Throttle(Throttlelevernotshownforthesakeofclarity)

1.Choke3.Slow

2.Fast

4.Off

g276362

Figure9

1.Blade-control-locklever4.Handle

2.Parkingbrake5.Drivebar

3.Blade-controlbar
