Toro 23210 - 1 Installing the Grinder Control Lever; 2 Checking Fluid Levels; Setup; 3 Charging the Battery

Setup
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
ProcedureDescription
Qty.
Use
Grindercontrollever
1
1
Jamnut1
Installthegrindercontrollever.
2
Nopartsrequired
–
Checktheuidlevels.
3
Nopartsrequired
–
Chargethebattery.
1
InstallingtheGrinderControl
Lever
Partsneededforthisprocedure:
1
Grindercontrollever
1Jamnut
Procedure
1.Threadthejamnutontothegrindercontrollever
(Figure4).
Figure4
1.Grindercontrollever
3.4-pinconnector
2.Jamnut
2.Threadthegrindercontrolleverintotherecepticle
onthecontrolpanel(Figure4).
3.Withthetriggerorientedforward,tightenthejam
nutagainstthereceptacletosecuretheleverinplace
(Figure4).
4.Connectthewireonthelevertothe4-pinconnector
underthecontrolpanel(
Figure4).
2
CheckingFluidLevels
NoPartsRequired
Procedure
Beforestartingtheengineforthersttime,check
theengineoilandhydraulicuidlevels;referto
CheckingtheEngineOilLevel(page16)and
CheckingtheHydraulicFluidLevel(page16)formore
information.
3
ChargingtheBattery
NoPartsRequired
Procedure
Chargethebattery;referto
ChargingtheBattery(page29)formoreinformation.
11
