Setup
Note: Determine the left and right sides of the machine from the normal operating position.
Loose Parts
Note: Use the chart below to verify all parts have been shipped.
DESCRIPTION QTY. USE
Fuel tank
Control panel
Bolt, 5/16 x 7/8 in.
Lock washer, 5/16 in.
Washer, 5/16
Spring
Stud
Hose clamp
1
1
2
2
4
2
2
1
Installing the fuel tank and the control panel
Shift lever
Rubber seal
Square hole washer
Spring washer
Locknut
1
1
1
1
1
Installing the shift lever to transmission
Upper handle
Flanged bolt 3/8 x 1 in.
Flange nut 3/8 in.
1
4
4
Installing the upper handle
Clevis pin
Washer
Hairpin cotter pin
1
1
2
Installing the control rods
Hairpin cotter pin 2 Installing the hairpin cotter pins
Operator’s Manual
Engine Operator’s Manual
Parts Catalog
Registration card
1
1
1
1
Read before operating machine
Read before operating machine
Fill out and return to Toro
Installing the Control Panel
and Fuel Tank
Note: Hardware to install control panel and fuel tank is
installed in the bottom of fuel tank.
1. Remove the bolts and nuts holding the control panel to
the rear frame. Discard these nuts and bolts.
2. Slide the control panel under the bottom of the rear
frame (Fig. 2).
