Toro 30252 - Checking the Tire Pressure; Draining the Fuel Tank

26
Where to Add Grease
• Grease the wheel bearings and front spindles (Fig. 34).
2147
Figure 34
• Grease the fitting on the spindle pulley bearing
(Fig. 41).
Note: You can access the spindle grease fitting through
the hole in the mower cover.
• Grease the transmission couplers (Fig. 35).
m–5191
Figure 35
Checking the Tire Pressure
Check the pressure at the valve stem after every 50
operating hours or monthly, whichever occurs first
(Fig. 36). Check the tires when they are cold to get the
most accurate pressure reading.
Pressure: 15 psi (103 kPa) rear and castor tires
1
Figure 36
1. Valve stem
Draining the Fuel Tank
Danger
In certain conditions, gasoline is extremely
flammable and highly explosive. A fire or
explosion from gasoline can burn you and others
and can damage property.
• Drain gasoline from the fuel tank when the
engine is cold. Do this outdoors in an open area.
Wipe up any gasoline that spills.
• Never smoke when draining gasoline, and stay
away from an open flame or where a spark may
ignite the gasoline fumes.
1. Park the machine on a level surface, to ensure that the
fuel tank drains completely.
2. Disengage the blade control (PTO), set the parking
brake, stop the engine, remove the key, and disconnect
the spark plug wire from the spark plug.
3. Close the fuel shut-off valve at the fuel tank (Fig. 37).
3
2
1
m
–
5183
Figure 37
1. Fuel shut-off valve
2. Clamp
3. Fuel line
4. Squeeze the ends of the hose clamp together and slide
it up the fuel line away from the valve (Fig. 37).
