ChargeIndicator
Illuminateswhenthechargingsystemcircuitmalfunctions
(Figure5).
OilPressureWarningLight
Theoilpressurewarninglight(Figure5)glowswhentheoil
pressureinenginedropsbelowasafelevel.Iflowoilpressure
everoccurs,stoptheengineanddeterminethecause.Repair
thedamagebeforestartingtheengineagain.
FuelGauge
Thefuelgauge(Figure6)indicatesthefuellevelremaining
inthefueltank.
Figure6
1.Fuelgauge2.Fueltankcap
CabControls
Models30540&30542only
WindShieldWiper/WasherSwitch
Presstherearoftheswitchtoactivatethewindshieldwipers
(Figure7)andthefrontofswitchtoactivatethewindshield
washer.Releasetheswitchtoturnoffthewasher.
AirConditioningSwitch
Pressthefrontoftheswitchtoactivatetheairconditioning
(Figure7)andtherearoftheswitchtoturnofftheair
conditioning.
Figure7
1.Windshieldwiper/washer
switch
3.Fancontrol
2.Airconditioningswitch4.Temperaturecontrol
FanControl
Rotatethefancontrolknobtoregulatethespeedofthefan
(Figure7).
TemperatureControl
Rotatethetemperaturecontrolknobtoregulatetheair
temperatureinthecab(Figure7).
HeaterShut-offValve
Closingtheheatershut-offvalve,locatedinengine
compartment(Figure8),willmaximizetheairconditioner
capacitytothecabduringthesummer.Duringthefall
conversion,fullyopenthevalve.
