g008837
Figure6
1.Weightgauge
4.Seatbackadjustinglever
2.Weightadjustinglever5.Armrestadjustingknob
(notshown-locatedunder
armrest)
3.ForeandAftadjusting
lever
WeightAdjustingLever
Adjustforoperatorweight(Figure6).Pulluponthe
levertoincreasetheairpressureandpushdownto
decreasetheairpressure.Theproperadjustmentis
attainedwhentheweightgaugeisinthegreenregion.
CabControls
Cabmodelonly
WindShieldWiperSwitch
Pressfrontofswitchtoactivatethewindshieldwipers
(Figure7)andrearofswitchtoturnoffthewipers.
AirConditioningSwitch
Pressfrontofswitchtoactivatetheairconditioning
(Figure7)andrearofswitchtoturnofftheair
conditioning.
FanControl
Rotatethefancontrolknobtoregulatethespeedof
thefan(Figure7).
TemperatureControl
Rotatethetemperaturecontrolknobtoregulatethe
airtemperatureinthecab(Figure7).
g008836
Figure7
1.Windshieldwiperswitch3.Fancontrol
2.Airconditioningswitch4.Temperaturecontrol
WindShieldLatch
Liftuponlatchestoopenthewindshield(Figure8).
Pressinonlatchtolockwindshieldinopenposition.
Pulloutanddownonlatchtocloseandsecurewind
shield.
g008830
Figure8
1.Windshieldlatch
RearWindowLatch
Liftuponlatchestoopentherearwindow.Pressin
onlatchtolockwindowinopenposition.Pulloutand
downonlatchtocloseandsecurewindow(Figure8).
Important:Therearwindowmustbeclosed
beforeopeningthehoodordamagemayoccur.
