Toro 36002 - Setup; Unfolding the Handle

Setup
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
ProcedureDescription
Qty.
Use
1
Nopartsrequired
–
Unfoldthehandle.
Bolt(1/4–20X1–1/2inches)
1
Locknut(1/4–20inch)
1
Carriagebolt(1/4–20x1inch)
3
Locknut(1/4–20inch)
3
2
Screw(1/4–20X5/8inch)
1
Installthedischargechute.
3
Nopartsrequired
–
Checktheengine-oillevel.
1
UnfoldingtheHandle
NoPartsRequired
Procedure
Important:Ensurethatthecablesarenotpinched
whenunfoldingthehandle.
Figure4
5
