Toro 37797 - Operating the Quick Stick

2.Tostoptheaugerandimpeller,releasetheright
lever.
Important:Whenyouengageboththe
auger/impellerleverandthetractionlever,
thetractionleverlockstheauger/impeller
leverdown,freeingyourrighthand.To
releasebothlevers,simplyreleasetheleft
(traction)lever.
3.Iftheaugerandimpellercontinuetorotatewhen
youreleasetheauger/impellerlever,donot
operatethemachine.Checktheauger/impeller
cable;refertoCheckingandAdjustingthe
Auger/ImpellerCable(page18)andadjustitif
necessary.Otherwise,takethemachinetoan
AuthorizedDealerforservice.
WARNING
Iftheaugerandimpellercontinue
torotatewhenyoureleasethe
auger/impellerlever,youcouldseriously
injureyourselforothers.
Donotoperatethemachine.Takeittoan
AuthorizedServiceDealerforservice.
OperatingtheQuickStick®
HoldthebluetriggercapdowntousetheQuickStick
tomovethedischargechuteandthechutedeector.
Releasethetriggercaptolockthedischargechute
andchutedeectorintoposition(Figure27).
g001014
Figure27
MovingtheDischargeChute
HoldthebluetriggercapdownandmovetheQuick
Sticktothelefttomovethedischargechutetothe
left;movetheQuickSticktotherighttomovethe
dischargechutetotheright(Figure28).
g018894
Figure28
•Ifthechutedoesnotmove,refertoAdjustingthe
Discharge-ChuteLatch(page21).
•Ifthechutedoesnotturnasfartotheleftasit
doestotheright,ensurethatthecableisrouted
totheinsideofthehandles.RefertoInstallingthe
UpperHandle(page5).
•Ifthechutedoesnotlockintoplacewhenyou
releasethetriggercap,refertoAdjustingthe
Discharge-ChuteLatch(page21).
MovingtheChuteDeector
HoldthebluetriggercapdownandmovetheQuick
Stickforwardtolowerthechutedeector;moveit
rearwardtoraisethechutedeector(Figure29).
g001016
Figure29
13
