Toro 37797 - Checking the Tire Pressure; Checking the Skids and Scraper; Checking the Operation of the Traction Drive

CheckingtheTirePressure
g219877
CheckingtheSkidsand
Scraper
RefertoCheckingandAdjustingtheSkidsand
Scraper(page17).
CheckingtheOperationof
theTractionDrive
CAUTION
Ifthetractiondriveisnotproperlyadjusted,
themachinemaymoveinthedirection
oppositeofwhatyouintended,causinginjury
and/orpropertydamage.
Carefullycheckthetractiondriveandadjustit
properly,ifnecessary.
1.Starttheengine;refertoStartingtheEngine
(page9).
2.MovethespeedselectortoPositionR1;referto
OperatingtheSpeedSelector(page12).
3.Squeezetheleft(traction)levertothehandgrip
(Figure11).
g001011
Figure11
Themachineshouldmoverearward.Ifthe
machinedoesnotmoveormovesforward,
completethefollowing:
A.Releasethetractionleverandshutoffthe
engine.
B.Disconnectthetrunnionfromthe
speed-selectorlever.
C.Turnthetrunniondownward(clockwise)on
thespeed-controlrod.
D.Connectthetrunniontothespeed-selector
lever.
4.Releasethetractionlever.
5.MovethespeedselectortoPosition1;referto
OperatingtheSpeedSelector(page12).
6.Squeezetheleft(traction)levertothehandgrip
(Figure11).
Themachineshouldmoveforward.Ifthe
machinedoesnotmoveormovesrearward,
completethefollowing:
A.Releasethetractionleverandshutoffthe
engine.
B.Disconnectthetrunnionfromthe
speed-selectorlever.
C.Turnthetrunnionupward(counterclockwise)
onthespeed-controlrod.
D.Connectthetrunniontothespeed-selector
lever.
7.Ifyoumadeanyadjustments,repeatthis
procedureuntilnoadjustmentsarerequired.
Important:Ifthemachinemoveswhenthe
tractionleverisinthereleasedposition,checkthe
tractioncable;refertoCheckingandAdjusting
theTractionCable(page18)ortakethemachine
toanAuthorizedServiceDealerforservice.
7
