CheckingtheEngine-Oil
Level
ServiceInterval:Beforeeachuseordaily—Check
theengine-oillevelandaddoilif
necessary.
g220487
CheckingandAdjustingthe
SkidsandScraper
ServiceInterval:Yearly—Checktheskidsand
thescraperandadjustthemif
necessary.
Checktheskidsandthescrapertoensurethatthe
augerdoesnotcontactthepavedorgravelsurface.
Adjusttheskidsandthescraperasneededto
compensateforwear.
1.Checkthetirepressure;refertoCheckingthe
TirePressure(page7).
2.Loosenthenutsthatsecurebothskidstothe
augersidesuntiltheskidsslideupanddown
easily.
g019046
Figure31
1.3mm(1/8inch)
Important:Theaugerbladesmustbe
supportedabovethegroundbytheskids.
3.Ensurethatthescraperis3mm(1/8inch)above
andparalleltoalevelsurface.
Note:Ifthepavementiscracked,rough,or
uneven,adjusttheskidstoraisethescraper.For
gravelsurfaces,adjusttheskidsfurtherdownto
preventthemachinefrompickinguprocks.
4.Movetheskidsdownuntiltheyareevenwith
theground.
5.Firmlytightenthenutsthatsecurebothskids
totheaugersides.
Note:Toquicklyadjusttheskidsiftheyloosen,
supportthescraper3mm(1/8inch)offthe
pavement,thenadjusttheskidsdowntothe
pavement.
Note:Iftheskidsbecomeexcessivelyworn,
youcanturnthemoverandsettheunusedside
towardthepavement.
