Toro 38614 - Filling the Engine with Oil; Checking the Tire Pressure

Note:Ensurethattheplasticcliponthewire
connectorisonthebottom(Figure17).
2.Secureacabletie(fromtheloosepartsbag)around
thewireandthehandleaboutaninch(2.5cm)below
theU-bolt(
Figure17).
6
FillingtheEnginewithOil
NoPartsRequired
Procedure
Yourmachinecomeswithoilintheenginecrankcase.
Note:Beforestartingtheengine,checktheoillevel
andaddoilifnecessary.
UseautomotivedetergentoilwithanAPIservice
classicationofSF,SG,SH,SJ,SL,orhigher.Referto
yourengineowner’smanual.
UseFigure18belowtoselectthebestoilviscosityfor
theoutdoortemperaturerangeexpected:
Figure18
1.UsingSAE30atoutdoor
temperaturesbelow40°F
(4°C)willresultinhard
starting.
2.Using10W-30atoutdoor
temperaturesabove
80°F(27°C)mayresultin
increasedoilconsumption;
therefore,checktheoil
levelmorefrequentlyin
thesecircumstances.
EngineOilCapacities
EngineOilCapacities(cont'd.)
Model
EngineOilCapacity
38614
38624
38624W
38634
18to20oz.(0.53to0.59l)
38644
38654
26to28oz.(0.77to0.83l)
1.Removethedipstickandslowlypouroilintotheoil
lltubetoraisetheoilleveltotheFullmarkonthe
dipstick.Donotoverll.(
Figure19).
Figure19
2.Installthedipsticksecurely.
Note:Donotspilloilaroundtheoillltube;oil
couldleakontotractionpartsandcausethetraction
toslip.
7
CheckingtheTirePressure
NoPartsRequired
Procedure
Thetiresareoverinatedatthefactoryforshipping.
Reducethepressureequallyinbothtirestobetween17
and20psi(116and137kPa).
