OperatingtheTractionDrive
CAUTION
Ifthetractiondriveisnotproperlyadjusted,the
machinemaymoveinthedirectionoppositeof
whatyouintended,causinginjuryand/orproperty
damage.
Carefullycheckthetractiondriveandadjustit
properly,ifnecessary;refertoCheckingtheTraction
DriveOperationinSetupformoreinformation.
Important:Ifthemachinemoveswhenthetraction
leverisinthereleasedposition,checkthetractioncable
(refertoCheckingandAdjustingtheTractionCable)or
takethemachinetoanAuthorizedServiceDealerfor
service.
1.Toengagethetractiondrive,squeezethelefthand
(traction)levertothehand-grip(Figure28).
Figure28
2.Tostopthetractiondrive,releasethetractionlever.
OperatingtheSpeedSelector
Thespeedselectorhas6forwardand2reversegears.To
changespeeds,releasethetractionleverandshiftthespeed
selectorlevertothedesiredposition(Figure29).Thelever
locksinanotchateachspeedselection.
Figure29
OperatingtheAuger/Impeller
Drive
1.Toengagetheauger/impellerdrive,squeezetheright
hand(auger/impeller)levertothehandgrip(Figure
30).
Figure30
2.Tostoptheaugerandimpeller,releasetherighthand
lever.
Important:Whenyouengageboththe
auger/impellerleverandthetractionlever,the
tractionleverlockstheauger/impellerleverdown,
freeingyourrighthand.Toreleasebothlevers,
simplyreleasethelefthand(traction)lever.
3.Iftheaugerandimpellercontinuetorotatewhenyou
releasetheauger/impellerlever,donotoperatethe
machine.Checktheauger/impellercable(referto
CheckingandAdjustingtheAuger/ImpellerCable)
andadjustitifnecessary.Otherwise,takethemachine
toanAuthorizedDealerforservice.
