Controls
•Auger/ImpellerDriveControlLever—Toengageboth
theaugerandimpeller,presstheleveragainsttheright
handgrip.Todisengage,releasethelever.
•TractionControlLever—Toengagethetraction(wheel
drive),presstheleveragainstthelefthandgrip.Tostop
thetraction,releasethelever.
•SpeedSelectorLever—Thiscontrolhas4positions:3
forwardspeedsand1reverse.Tochangespeeds,move
thespeedselectorlevertothedesiredposition.Thelever
locksinanotchateachspeedselection.
Note:Beforeshiftinggearsintooroutofreverse,you
mustreleasethetractioncontrollever.Youmayshift
betweenanyoftheforwardspeedswithoutreleasingthe
tractioncontrollever.
•DischargeChuteControl—Rotatethedischargechute
controlclockwisetomovethedischargechutetotheleft;
counterclockwisetomovethechutetotheright.
•ChuteDeectorHandle—Movethedeectorhandle
forwardtomovethesnowstreamdown;moveitrearward
tomovethesnowstreamup.
•FuelshutoffValve—Closethevalvebyrotating
clockwise.Openthevalvebyrotatingitcounterclockwise.
Closethevalvewhenyoudonotusethemachine.
•IgnitionSwitch—Inserttheignitionkeybeforestarting
theengine.Tostoptheengine,removethekey.
•Choke—RotatethechoketotheFullpositiontostarta
coldengine.Asenginewarmsup,graduallyrotatethe
choketotheOffposition.
•ThrottleLever—Movethethrottlelevertotherightto
increasetheenginespeed;moveittothelefttodecrease
theenginespeed.MovethethrottlelevertotheStop
positiontostoptheengine.
•Primer—Presstheprimertopumpasmallamount
ofgasolineintotheengineforimprovedcold-weather
starting.
•ElectricStarter—Theelectricstarterisontherightside
oftheengine.Tostartthemachine,connecttheelectric
startertoanelectricpowersourcewithanapproved
extensioncordandpressthestarterbutton.
•RecoilStarter—Therecoilstarterisonthebacksideof
theengine.Pulltherecoilstartertostarttheengine.
•SnowClean-outTool—Thesnowclean-outtoolison
thetopoftheaugerhousing.Usethistooltounclogthe
dischargechutewhenitbecomescloggedwithsnow.
Operation
Note:Determinetheleftandrightsidesofthemachine
fromthenormaloperatingposition.
FreewheelingorUsingthe
Self-propelDrive
Youcanoperatethemachinewiththeself-propelfeature
engagedordisengaged(freewheeling).
Tofreewheel,slidethewheelsinwardandinserttheaxle
pinsthroughtheaxleholes,butnotthroughthewheelhubs
(Figure16).
Figure16
Toself-propel,slidethewheelsoutwardandinserttheaxle
pinsthroughtheholesinthewheelhubsandtheaxleholes
(Figure17).
Figure17
FillingtheFuelTank
DANGER
Gasolineisextremelyammableandexplosive.A
reorexplosionfromgasolinecanburnyouand
others.
•Topreventastaticchargefromignitingthe
gasoline,placethecontainerand/ormachine
onthegroundbeforelling,notinavehicleor
onanobject.
•Fillthetankoutdoorswhentheengineiscold.
Wipeupspills.
•Donothandlegasolinewhensmokingoraround
anopenameorsparks.
•Storegasolineinanapprovedfuelcontainer,out
ofthereachofchildren.
•Forbestresults,useonlyclean,fresh,unleadedgasoline
withanoctaneratingof87orhigher((R+M)/2rating
method).
•Oxygenatedfuelwithupto10%ethanolor15%MTBE
byvolumeisacceptable.
15
