Toro 74141 - Adjusting the Anti-Scalp Rollers; Positioning the Seat

AdjustingtheHeight-of-CutPin
Mowerdecksize
Height-of-cut
range
Increments
48-inchdeck38to127mm
(1-1/2to5inches)
6mm(1/4inch)
52-inchand
60-inchdecks
38to140mm
(1-1/2to5-1/2
inches)
6mm(1/4inch)
Theheight-of-cutisadjustedfrom25to140mm(1to
5-1/2inches)in6mm(1/4inch)incrementsbyrelocating
theclevispinintodifferentholelocations.
1.Movethetransportlocktothelockposition.
2.Pushonthedeck-liftpedalwithyourfoot,andraisethe
mowerdecktothetransportposition(alsothe140mm
(5-1/2inches)cuttingheightposition)asshownin
Figure25.
3.Toadjust,rotatethepin90degreesandremovethepin
fromtheheight-of-cutbracket(Figure25).
4.Selectaholeintheheight-of-cutbracketcorresponding
totheheight-of-cutdesired,andinsertthepin(Figure
25).
5.Pushonthedecklift,pullbackonthetransportlock,
andslowlylowerthemowerdeck.
g017419
2
1
3
Figure25
1.Deck-liftpedal
3.Transportlock
2.Cut-of-heightpin
AdjustingtheAnti-Scalp
Rollers
Wheneveryouchangetheheight-of-cut,itisrecommended
toadjusttheheightoftheanti-scalprollers.
1.Disengagetheblade-controlswitch(PTO),movethe
motion-controlleverstotheneutral-lockedposition,
andsettheparkingbrake.
2.Stoptheengine,removethekey,andwaitforallmoving
partstostopbeforeleavingtheoperatingposition.
g017628
Figure26
1.Anti-scalproller4.Flangenut
2.Spacer
5.Bolt
3.Bushing
g017629
Figure27
1.Anti-scalproller3.Flangenut
2.Bushing4.Bolt
PositioningtheSeat
Theseatcanmoveforwardandbackward.Positiontheseat
whereyouhavethebestcontrolofthemachineandaremost
comfortable.
Toadjust,movetheleversidewaystounlockseat(Figure28).
G008962
Figure28
24
