Toro 74141 - Replacing the Grass Deflector

g017417
2
Figure84
1.Removethereardeckliftattachmentshoulderboltandnut.
2.Removethefrontdeckliftattachmentshoulderboltandnut.
8.Slidethedeckouttotherightsideofthemachine.
ReplacingtheGrassDeector
WARNING
Anuncovereddischargeopeningcouldallowthe
lawnmowertothrowobjectsintheoperator'sor
bystander'sdirectionandresultinseriousinjury.
Also,contactwiththebladecouldoccur.
Donotoperatethelawnmowerunlessyouinstalla
coverplate,amulchplate,grassdeectororbagger.
1.Removethelocknut,thebolt,thespring,andthespacer
holdingthedeectortothepivotbrackets(Figure85).
2.Removethedamagedorworngrassdeector(Figure
85).
g015594
1
6 2
4
7
3
5
Figure85
1.Bolt
5.Springinstalled
2.Spacer6.Grassdeector
3.Locknut
7.J-hookendofspring
4.Spring
3.Placethespacerandthespringontograssdeector.
4.PlaceoneJ-endofthespringbehindthedeckedge.
Note:MakesureoneJ-endofthespringisinstalled
behindthedeckedgebeforeinstallingtheboltas
showninFigure85.
5.Installtheboltandthenut.
6.PlaceoneJ-hookendofthespringaroundthegrass
deector(Figure85).
Important:Thegrassdeectormustbeable
torotate.Liftthedeectoruptothefullopen
positionandensurethatitrotatesintothefull
downposition.
55
