Toro 74143 - Adjusting the Motion-Control Damper; Adjusting the Motion Control Neutral-Lock Pivot

AdjustingtheMotion-Control
Damper
Thetopdamper-mountingboltcanbeadjustedtoobtaina
moredesiredmotion-controlleverresistance.SeeFigure66
formountingoptions.
Figure66
RHMotionControlShown
1.Torquethelocknutto23N-m(17ft-lb).Theboltmust
protrudepasttheendofthelocknutaftertorquing.
2.Mostresistance(rmestfeel)
3.Damper
4.Mediumresistance(mediumfeel)
5.Leastresistance(softestfeel)
AdjustingtheMotionControl
Neutral-LockPivot
Theangednutcanbeadjustedtoobtainamoredesired
motion-controlleverresistancewhenmovingittothe
neutral-lockposition.SeeFigure67foradjustmentoptions.
1.Loosenthejamnut.
2.Tightenorloosentheangednuttothedesiredfeel.
Note:Formoreresistance,tightentheangednut.
Note:Forlessresistance,loosentheangednut
3.Tightenthejamnut.
Figure67
1.Flangednut2.Jamnut
47
