Figure50
3.Installnewbeltaroundengineandhydropump
pulleys(Figure50).
4.Pullspringloadedidlerdownandalignbelow
tractionbelt.Releasethepressureonthespring
loadedidler(Figure50).
ControlsSystem
Maintenance
AdjustingtheControlHandle
NeutralPosition
Ifmotioncontrolleversdonotalign,ormoveeasilyinto
theconsolenotch,adjustmentisrequired.Adjusteach
lever,springandrodseparately.
Note:Motioncontrolleversmustbeinstalledcorrectly.
SeeInstallingtheMotionControlLeversinthesetup
instructions.
1.DisengagethePTO,movethemotioncontrollevers
totheneutrallockedpositionandsettheparking
brake.
2.Stoptheengine,removethekey,andwaitforall
movingpartstostopbeforeleavingtheoperating
position.
3.Unlatchtheseatandtilttheseatforward.
4.Beginwitheithertheleftorrightmotioncontrol
lever.
5.Movethelevertotheneutralpositionbutnotlocked
(Figure51).
Figure51
1.Neutrallockedposition3.Neutralposition
2.Controllever
6.Pulltheleverbackuntiltheclevispin(onarm
belowpivotshaft)contactstheendoftheslot(just
beginningtoputpressureonthespring)(Figure51).
7.Checkwherethecontrolleverisrelativetonotchin
console(Figure51).Itshouldbecenteredallowing
levertopivotoutwardtotheneutrallockposition.
8.Ifadjustmentisneeded,loosenthenutandjamnut
againsttheyoke(Figure52).
