2. Install the positi v e (red) batter y cable to the
positi v e (+) batter y ter minal.
3. Install the neg ati v e batter y cable to the neg ati v e
(-) batter y ter minal.
4. Secure the cables with 2 bolts (1/4 x 3/4 inc h),
w ashers (1/4 inc h), and wing n uts (1/4 inc h)
( Figure 32 ).
5. Slide the red ter minal boot onto the positi v e
(red) batter y post.
6. Secure the batter y with the hold-do wn
( Figure 32 ).
Servicing the Fuses
T he electrical system is protected b y fuses . It
requires no maintenance; ho w ev er , if a fuse blo ws ,
c hec k the component/circuit for a malfunction
or shor t.
Fuse:
• Main F1-30 amp , blade-type
• Charg e Circuit F2-25 amp , blade-type
• Optional Headlight Kit-10 amp , blade type
1. Raise the seat to g ain access to the fuse holder
( Figure 34 ).
2. T o re place a fuse , pull out on the fuse to
remo v e it ( Figure 34 ).
Figure 34
1. Main-30 amp
3. For optional Headlight
Kit-10 amp
2. Charge circuit-25 amp
4. Battery
Drive System
Maintenance
Checking the Tire Pressure
Maintain the air pressure in the front and rear
tires as specified. Unev en tire pressure can cause
unev en cut. Chec k the pressure at the v alv e
stem after ev er y 50 operating hours or monthly ,
whic hev er occurs first ( Figure 35 ). Chec k the
tires when they are cold to g et the most accurate
pressure reading .
R ear Tires: 13 psi (90 kP a)
F ront Tires (castor wheels): 35 psi (139 kP a)
Figure 35
1. Valve stem
Mower Maintenance
Servicing the Cutting Blades
Maintain shar p blades throughout the cutting
season because shar p blades cut cleanly without
tearing or shredding the g rass blades . T earing and
shredding tur ns g rass bro wn at the edg es , whic h
slo ws g ro wth and increases the c hance of disease .
Chec k the cutter blades daily for shar pness , and
for any w ear or damag e . File do wn any nic ks
and shar pen the blades as necessar y . If a blade is
damag ed or w or n, re place it immediately with a
g en uine T oro re placement blade . F or con v enient
shar pening and re placement, y ou ma y w ant to
k ee p extra blades on hand.
28
