Figure7
1.Safetyinterlocksymbols
3.Hourmeter
2.Batterylight
ThrottleControl
ThethrottlecontrolisvariablebetweenFastandSlow.
Choke
Usethechoketostartacoldengine.
BladeControlSwitch(PTO)
Thebladecontrolswitch(PTO)isusedtoengage
theelectricclutchtodrivethemowerbladeswiththe
rightsidemotioncontrolleverinthecenter,un-locked
position.Pulltheswitchuptoengagethebladesand
release.Todisengagetheblades,pushthebladecontrol
switch(PTO)downormoveorreleasetherightside
motioncontrolleverintotheneutrallockposition.
IgnitionSwitch
Thisswitchisusedtostartthemowerengineandhas
threepositions:Off,RunandStart.
MotionControlLevers
Themotioncontrolleversareusedtodrivethemachine
forward,reverse,andturneitherdirection.
FuelShut-offValve
Closethefuelshut-offvalve(locatedbehindthe
operatorcushionontherighthandsideofthefueltank)
whentransportingorstoringthemower.
Attachments/Accessories
AselectionofToroapprovedattachmentsand
accessoriesareavailableforusewiththemachineto
enhanceandexpanditscapabilities.Contactyour
AuthorizedServiceDealerorDistributororgoto
www.Toro.comforalistofallapprovedattachments
andaccessories.
Specications
Note:Specicationsanddesignaresubjecttochange
withoutnotice.
48inchmowers:
Widthwithdeectordown63.5inches(161.3cm)
Lengthwithplatformdown74inches(188cm)
Lengthwithplatformup58inches(147.3cm)
Height
48inches(121.9cm)
Weightwith20hpengine
881(399.6kg)
Weightwith24hpengine
888(402.8kg)
52inchmowers:
Widthwithdeectordown67.5inches(171.4cm)
Lengthwithplatformdown74inches(188cm)
Lengthwithplatformup58inches(147.3cm)
Height
48inches(121.9cm)
Weightwith20hpengine
883(400.5kg)
Weightwith24hpengine
900(408.2kg)
60inchmowers:
Widthwithdeectordown75.67inches(192.2cm)
Lengthwithplatformdown74inches(188cm)
Lengthwithplatformup58inches(147.3cm)
Height
48inches(121.9cm)
Weightwith26hpengine
925(419.5kg)
