Toro 74538 - Replacing the Grass Deflector

G015501
1
2
3
4
Figure89
60inchmowerdecks
1.Adjustmentrods
3.Liftlink
2.Rearnuts4.Frontnuts
MatchingHeightofCut
1.Checkthereartirepressure.
2.Settheheight-of-cuttothe3inch(7.6cm)position.
RefertoAdjustingtheHeight-Of-CutinOperation.
3.Withthemachineonlevelsurface,positiononeblade
front-to-rear.MeasureatAandfromlevelsurfaceto
thecuttingedgeofthebladetips(
Figure90).
Figure90
1.Measurefromalevel
surface
2.MeasurebladeatpointA
4.Themeasurementshouldbe3inch(7.6cm).
5.Ifitdoesnotmeasurecorrectly,locatethe
height-of-cutrodontherightsideofthemachine
(
Figure91).
6.Adjusttheadjustmentboltuntilthebladetipsmatch
3inches(7.6cm)(Figure91).
g015336
1
2
Figure91
1.Height-of-cutrod
2.Adjustmentbolt
ReplacingtheGrassDeector
WARNING
Anuncovereddischargeopeningcouldallowthe
lawnmowertothrowobjectsintheoperator’sor
bystander’sdirectionandresultinseriousinjury.
Also,contactwiththebladecouldoccur.
Neveroperatethelawnmowerunlessyouinstalla
coverplate,amulchplate,grassdeectororbagger.
