Toro 74538 - Release the Cushion for Rear Access

Figure36
1.Removebattery
2.Withtwopeople,liftthe
frontendofthemower
(ensuretheplatformisup)
ReleasetheCushionforRear
Access
Thecushioncanbereleasedforrearaccesstothe
machineformaintenanceoradjustment.
1.Lowertheplatform.
2.Removethehairpincotterpinsoneachsideofthe
cushion.
3.Slidethelargewasherswithplasticbushingstothe
inside.
4.Removethecushionandlowerittotheplatform.
5.Performanymaintenanceoradjustmentonthe
machine.
6.Raisethecushionandslideitontothepinsonboth
sidesofthemachine(Figure37).
7.Slidethelargewashersplasticbushingsintothe
cushionbracketandsecurethemwithahairpin
cotterpin(
Figure37).
Figure37
1.Plasticbushingwithlarge
washer
3.Hairpincotterpin
2.Cushionbracketwithkey
hole
30
