Toro 74538 - Adjusting the Caster Pivot Bearing; Servicing the Caster Wheel and Bearings

Figure59
AdjustingtheCasterPivot
Bearing
ServiceInterval:Every500hours/Yearly(whichever
comesrst)
1.Disengagethebladecontrolswitch(PTO),movethe
motioncontrolleverstotheneutrallockedposition
andsettheparkingbrake.
2.Stoptheengine,removethekey,andwaitforall
movingpartstostopbeforeleavingtheoperating
position.
3.Removethedustcapfromcasterandtightenlock
nut(
Figure60).
4.Tightenthelocknutuntilthespringwashersareat
andthenbackoffa1/4turntoproperlysetthe
pre-loadonthebearings(
Figure60).
Important:Makesurespringwashersare
installedcorrectlyasshowninFigure60.
5.Installthedustcap(Figure60).
Figure60
1.SpringWashers3.DustCap
2.LockNut
ServicingtheCasterWheel
andBearings
Thecasterwheelsrotateonarollerbearingsupportedby
aspannerbushing.Ifthebearingiskeptwelllubricated,
wearwillbeminimal.Failuretokeepthebearingwell
lubricatedwillcauserapidwear.Awobblycasterwheel
usuallyindicatesawornbearing.
1.Removethelocknutandwheelboltholdingthe
casterwheeltothecasterfork(
Figure61).
Figure61
1.Locknut
4.SpannerBushing
2.WheelBolt5.RollerBearing
3.Bushing
