Toro 74765 - Table of Contents; Figure

Figure2
1.Safety-alertsymbol
Thismanualuses2wordstohighlightinformation.
Importantcallsattentiontospecialmechanicalinformation
andNoteemphasizesgeneralinformationworthyofspecial
attention.
Important:Ifyouareusingthismachineabove1500m
(5,000ft)foracontinuousperiod,ensurethattheHigh
AltitudeKithasbeeninstalledsothattheenginemeets
CARB/EPAemissionregulations.TheHighAltitude
Kitincreasesengineperformancewhilepreventing
spark-plugfouling,hardstarting,andincreased
emissions.Onceyouhaveinstalledthekit,attach
thehigh-altitudelabelnexttotheserialdecalonthe
machine.ContactanyAuthorizedToroServiceDealer
toobtaintheproperHighAltitudeKitandhigh-altitude
labelforyourmachine.Tolocateadealerconvenientto
you,accessourwebsiteatwww.Toro.comorcontactour
ToroCustomerCareDepartmentatthenumber(s)listed
inyourEmissionControlWarrantyStatement.
Removethekitfromtheengineandrestoretheengine
toitsoriginalfactorycongurationwhenrunningthe
engineunder1500m(5,000ft).Donotoperateanengine
thathasbeenconvertedforhigh-altitudeuseatlower
altitudes;otherwise,youcouldoverheatanddamage
theengine.
Ifyouareunsurewhetherornotyourmachinehasbeen
convertedforhigh-altitudeuse,lookforthefollowing
label(Figure3).
Figure3
Contents
Safety...........................................................................4
SafeOperatingPractices...........................................4
ToroRidingMowerSafety........................................6
SlopeIndicator.......................................................7
SafetyandInstructionalDecals.................................8
ProductOverview.........................................................12
Controls...............................................................12
Operation....................................................................14
AddingFuel...........................................................14
CheckingtheEngine-OilLevel.................................15
BreakinginaNewMachine......................................15
ThinkSafetyFirst...................................................15
UnderstandingtheSafety-InterlockSystem................16
TestingtheSafety-InterlockSystem...........................16
StartingtheEngine.................................................17
OperatingtheBlades...............................................17
ShuttingOfftheEngine..........................................17
DrivingtheMachine...............................................18
StoppingtheMachine.............................................20
AdjustingtheHeightofCut.....................................20
PositioningtheSeat................................................20
AdjustingtheMotion-ControlLevers........................20
PushingtheMachinebyHand..................................21
AdjustingtheAnti-ScalpRollers...............................22
TransportingtheMachine........................................22
LoadingtheMachine..............................................22
OperatingTips......................................................24
Maintenance.................................................................25
RecommendedMaintenanceSchedule(s)......................25
PremaintenanceProcedures........................................26
RaisingtheSeat......................................................26
Lubrication...............................................................26
GreasingtheBearings.............................................26
EngineMaintenance..................................................27
ServicingtheAirCleaner.........................................27
ServicingtheEngineOil..........................................28
ServicingtheSparkPlug..........................................30
FuelSystemMaintenance...........................................31
ReplacingtheIn-LineFuelFilter...............................31
ElectricalSystemMaintenance....................................32
ChargingtheBattery...............................................32
ServicingtheFuses.................................................34
DriveSystemMaintenance.........................................34
CheckingtheTirePressure......................................34
ReleasingtheElectricBrake.....................................35
CoolingSystemMaintenance......................................35
CleaningtheEngineScreen......................................35
CleaningtheEngine-CoolingFinsand
Shrouds.............................................................35
MaintainingMower....................................................36
ServicingtheCuttingBlades.....................................36
LevelingtheMowerDeck........................................38
RemovingtheMower..............................................40
InstallingtheMower...............................................41
ReplacingtheGrassDeector..................................41
MaintainingtheMowerBelt(s).....................................42
ServicingtheMowerBelt(s).....................................42
Cleaning...................................................................44
WashingtheUndersideoftheMower........................44
Storage........................................................................45
CleaningandStoringtheMachine.............................45
Troubleshooting...........................................................46
Schematics...................................................................48
3
