g009682
Figure51
1.Bladessidetoside
3.Outsidecuttingedges
2.Sailareaofblade4.Measurefromthetipofthe
bladetotheatsurface
here
5.Measurebetweentheoutsidecuttingedges
andtheatsurface(Figure51).Ifboth
measurementsarenotwithin5mm(3/16inch),
anadjustmentisrequired;continuewiththis
procedure.
6.Movetotheleftsideofthemachine.
7.Loosenthesidelocknut.
8.Raiseorlowertheleftsideofthemowerdeck
byrotatingtherearnut.(Figure52).
Note:Rotatetherearnutclockwiseto
raisethemowerdeck;rotatetherearnut
counter-clockwisetolowerthemowerdeck.
g027588
Figure52
1.Hangerbracket3.Rearlocknut
2.Sidelocknut
9.Checktheside-to-sideadjustmentsagain.
Repeatthisprocedureuntilthemeasurements
arecorrect.
10.Continuelevelingthedeckbycheckingthe
front-to-rearbladeslope;refertoAdjustingthe
Front-to-RearBladeSlope(page40).
