Toro 74891 - Product Overview; Controls

ProductOverview
Figure4
1.Drivewheel4.Motion-controllevers7.Frontcasterwheel
10.Deector
2.Operatorseat
5.Parkingbrake8.Anti-scalproller
3.RolloverProtectionSystem
(ROPS)
6.Footrest
9.Footpedaldeckliftand
heightofcut
Controls
Becomefamiliarwithallthecontrolsbeforeyoustartthe
engineandoperatethemachine(Figure5).
Figure5
1.Throttlecontrol4.Ignitionswitch
2.Choke
5.Blade-controlswitch
(PTO)
3.Hourmeter
13
