HydraulicSystem
Maintenance
OilType:ToroHYPR-OIL®500or20W-50motoroil.
SystemCapacity:4.495L(152oz)withalterchange.
Important:Useoilspeciedorequivalent.Otheruids
couldcausesystemdamage.
CheckingtheHydraulic-Fluid
Level
ServiceInterval:Every25hours
Checktheexpansionreservoir,and,ifnecessary,adduid
totheFullColdline.
G010253
1
2
3
Figure50
1.Expansionreservoir3.Engine
2.FullColdline
ChangingtheHydraulicFilter
andFluid
Thelteranduidarechangedatthesametime.Oncethe
newlterisinstalledanduidisadded,anyairinthesystem
mustbepurged.
Thebleedingprocessisrepeateduntiltheuidremainsat
theFullColdlineinthereservoirafterpurging.Failureto
properlyperformthisprocedurecanresultinirreparable
damagetothetransaxledrivesystem.
RemovingtheHydraulicFilters
Important:Whenthehydrauliclterisremoved,allof
thehydraulicuidineachtransaxlewilldrainout.Usea
containerthatholds4.495L(152oz)orlarger.
1.Shutofftheengine,waitforallmovingpartstostop,
allowtheenginetocool,removethekey,andengage
theparkingbrake.
2.Locatethelterandguardsoneachtransaxledrive
systemandremovethe3screwssecuringthelter
guard(Figure51).
G010254
1
2
3
4
5
Figure51
Rightsideshown
1.Transaxledrive
4.Screws
2.Hydrauliclter
5.Ventplug
3.Filterguard
3.Carefullycleantheareaaroundthelters.
Important:Donotallowdirttoenterthe
hydraulicsystem,asitmaycausedamage.
4.Placeacontainerbelowthelteranddraintheuid.
5.Locateandremovetheventplugoneachtransmission.
6.Unscrewthelterandallowtheuidtodrainfrom
thedrivesystem.
7.Repeatthisprocedureforbothlters.
InstallingtheHydraulicFilter
ServiceInterval:Aftertherst50hours
Every400hours
1.Usingthe3screwstoinstallthelterguardsovereach
lterremovedpreviously.
2.Verifythattheventplugsareremovedbeforeadding
theuid.
3.Slowlypourthespecieduidthroughtheexpansion
reservoiruntiluidcomesoutofavent-plughole.
4.Installtheventplugandtorqueitto20N•m(180in-lb).
5.Continuetoadduidthroughtheexpansionreservoir
untiluidcomesoutoftheremainingvent-plughole
onthesecondtransmission.
