Figure54
1.Pullthistabouttothe
sideinthedirectionofthe
arrow.
3.Pulltheshroudoffthis
frametabinthedirection
ofthearrow.
2.Pulltheshroudoffthis
frametabinthedirection
ofthearrow.
4.Shroud
4.Removethesparkplug(Figure55).
g029646
g027478
Figure55
5.Installthelefthydraulic-unitshroud(Figure54).
CheckingtheSparkPlug
Important:Donotcleanthesparkplug(s).
Alwaysreplacethesparkplug(s)whenithas:a
blackcoating,wornelectrodes,anoilylm,or
cracks.
Ifyouseelightbrownorgrayontheinsulator,the
engineisoperatingproperly.Ablackcoatingonthe
insulatorusuallymeanstheaircleanerisdirty.
Setthegapto0.75mm(0.03inch).
g027479
Figure56
InstallingtheSparkPlug
Tightenthesparkplug(s)to22N∙m(16ft-lb).
g027735
Figure57
