Toro CM Series - Hitching Methods; Stamped Ball Coupler Hitching; Forged Ball Coupler Hitching

HitchingaMachinewithaStampedBall
Coupler
1.Applychassisgreasetothesocketofthecouplerand
theareaoftheclampthatcontactstheball.
2.Oilthepivotpointsandslidingsurfacesofthecoupler
withSAE30motoroil.
3.HitchthemachineasshowninFigure22.
Figure22
4.Ifthemachineisequippedwithatrailer-lightkit,
connectthewireplugofthetowvehicletothewire
plugofthemachine.
HitchingaMachinewithaForgedBall
Coupler
1.Applyremovablethread-lockingcompoundtothe
threadsofthecouplerbolttopreventthecoupler
handlefromcomingloose.
Important:Applythread-lockingcompoundas
neededinthefuture.
2.Applychassisgreasetothesocketofthecouplerand
theareaoftheclampthatcontactstheball.
3.InstallhitchthemachineasshowninFigure23.
Figure23
Note:Useawrenchtokeeptheboltfromspinning.
4.Ifthemachineisequippedwithatrailer-lightkit,
connectthewireplugofthetowvehicletothewire
plugofthemachine.
18
