Toro DH 210 User Manual

DANGER
Youcouldbackoverachildorbystanderwhilethe
mowerbladesorotherattachmentisengagedand
causeseriousinjuryordeath.
•Donotmowinreverseunlessitisabsolutely
necessary.
•DonotinserttheKeyChoicekeyunlessitis
absolutelynecessary.
•Alwayslookbackwardanddownbefore
backingupthemachine.
•UsetheKeyChoiceswitchonlyifyouare
certainthatnochildrenorotherbystanderswill
enterthemowingarea.
•Beveryobservantafterdeactivatingthe
interlockbecausethesoundoftheengine
maypreventyoufromnoticingthatachildor
bystanderhasenteredtheworkarea.
•AlwaysremoveboththeignitionandKeyChoice
keysandputtheminasafeplaceoutofthe
reachofchildrenorunauthorizeduserswhen
youleavethemachineunattended.
1.Engagetheblades(PTO).
2.InserttheKeyChoicekeyintotheswitch(Figure13).
3.TurntheKeyChoicekey.
Aredlightonthefrontconsole(Figure14)turns
on,indicatingthattheinterlockisdisabled.
G012080
1
Figure14
1.Operating-in-reverselight
4.Operatethemachineinreverseandcompleteyour
task.
5.Disengagetheblades(PTO)toactivatethe
interlock.
6.RemovetheKeyChoicekeyandputitinasafeplace
outofthereachofchildren.
TestingtheSafetyInterlock
System
CAUTION
Ifthesafetyinterlockswitchesaredisconnectedor
damaged,themachinecouldoperateunexpectedly,
causingpersonalinjury.
•Donottamperwiththeinterlockswitches.
•Checktheoperationoftheinterlockswitches
dailyandreplaceanydamagedswitchesbefore
operatingthemachine.
Testthesafetyinterlocksystembeforeyouusethe
machineeachtime.Ifthesafetyinterlocksystemdoes
notoperateasdescribedbelow,haveanAuthorized
ServiceDealerrepairthesafetyinterlocksystem
immediately.Whilesittingintheseat,performthe
followingchecks:
1.Settheparkingbrake,shiftthebladecontrol(PTO)
knobtotheEngageposition,andturntheignition
keytoStart:Theengineshouldnotcrank.
2.Shiftthebladecontrol(PTO)knobtotheDisengage
position,releasetheparkingbrake,andturnthe
ignitionkeytoStart:Theengineshouldnotcrank.
3.Settheparkingbrake,shiftthebladecontrol(PTO)
knobtoDisengage,andstarttheengine.Whilethe
engineisrunning,releasetheparkingbrakeandrise
slightlyfromtheseat:Theengineshouldstop.
4.Shiftthebladecontrol(PTO)knobintothe
Disengageposition,putthetractioncontrolpedal
inNeutral,andstarttheengine.Whiletheengine
isrunning,shiftthebladecontrol(PTO)knobinto
theEngagepositionandputthetractioncontrol
pedalinReverse:Theengineshouldstop.
5.Shiftthebladecontrol(PTO)knobintothe
Disengagepositionandputthetractioncontrol
pedalinNeutral.Starttheengine,shifttheblade
control(PTO)knobintotheEngageposition,
andturntheKeyChoicekeyandreleaseit:The
operating-in-reversewarninglightshouldilluminate.
6.Shiftthebladecontrol(PTO)knobtotheDisengage
position:Theoperating-in-reversewarninglight
shouldturnoff.
PushingtheMachineManually
Important:Alwayspushthemachinemanually.
Nevertowthemachinebecauseitmaydamage
thetransaxle.
