Blade Service (continued)
G447261
Blade edge previous measured
Opposite blade edge
5. Measure from the tip of the blade to the level surface.
G447260
Blade (in position for measuring)
Level surface
Measured distance between blade
and the surface (B)
6. If the difference between A and B is greater than 3 mm (1/8 inch), replace the blade.
Note: If you replace the blade and the difference continues to exceed 3 mm (1/8 inch),
the blade motor shaft could be bent. Contact an Authorized Service Dealer for service.
7. Repeat this procedure each blade.
Removing the Blades
Replace the blades if they hit a solid object, or if the blade is out of balance or bent.
G448104
1. Hold the blade end using a rag or thickly
padded glove.
2. Remove the blade as shown.
Maintenance: Mower-Deck Maintenance Page 5–8 3463-565 A
