Toro Flex-Force Power System 39901 - Adjusting the Discharge Chute

g268087
Figure14
1.LEDindicatorlight
2.Chargerventingareas
5.Toremovethebatterypack,slidethebattery
backwardoutofthecharger.
6.RefertothefollowingtabletointerprettheLED
indicatorlightonthebatterycharger.
IndicatorlightIndicates
Off
Nobatterypackinserted
Greenblinking
Batterypackischarging
Green
Batterypackischarged
Red
Batterypackand/orbattery
chargerisoverorunderthe
appropriatetemperaturerange
Redblinking
Batterypackchargingfault*
*RefertoTroubleshooting(page16)formore
information.
AdjustingtheDischarge
ChuteandChuteDeector
Toadjustthedischargechute,movethehandleon
thechute-controlrodinthedirectionthatyouwishto
directthesnowstream.
Toadjustthechutedeector(andthereforetheheight
ofthesnowstream),squeezethetriggerandraiseor
lowerthechutedeector(Figure15).
g318452
Figure15
1.Chutedeectortrigger
WARNING
Agapbetweenthedischargechuteandthe
chutedeectormayallowthemachineto
throwsnowandobjectsinthedirectionofthe
operator.Thrownobjectscouldcauseserious
personalinjury.
•Donotforcethechutedeectortoofar
forwardsothatagapappearsbetweenthe
dischargechuteandchutedeector.
•Donotadjustthechutedeectorwiththe
powercontrolbarengaged.Releasethe
powercontrolbarbeforeadjustingthe
chutedeector.
13
